treeview

A tree of checkboxes, based on bootstrap-treeview, that submits the ids of the checked nodes. The tree is loaded by AJAX or passed as static data.

Signature

Lte3::treeview(string $name, array $attrs = [])

The component has no value argument: which nodes are checked is part of the tree data (state.checked).

Basic example

{!! Lte3::treeview('category_ids', [
    'label' => 'Categories',
    'url_tree' => route('admin.categories.treeview', ['selected' => $product->categories->pluck('id')->all()]),
]) !!}

{!! Lte3::treeview('models', [
    'label' => 'Static data',
    'data' => $tree,
]) !!}

Attrs

Attr	Type	Default	Description
url_tree	string	-	Endpoint returning the tree, see Endpoint.
data	array	-	Static tree in the bootstrap-treeview node format. Used when url_tree is not set.
label	string	Str::studly($name)	Card title HTML. '' removes the card header.
class_wrap	string	-	Extra classes of the wrapper .card.f-treeview-wrap.

The field is rendered as an AdminLTE card with a loading overlay that disappears when the tree is built. It does not show validation errors or help text.

Node format

bootstrap-treeview nodes:

[
    [
        'id' => 1,
        'text' => 'Parent 1',
        'state' => ['expanded' => true, 'checked' => true],
        'nodes' => [
            ['id' => 11, 'text' => 'Child 1'],
        ],
    ],
    ['id' => 2, 'text' => 'Parent 2'],
]

• id — the submitted value. Required for every node.
• text — the node title.
• nodes — children.
• state — checked, expanded, disabled, selected.
• Other bootstrap-treeview node options (href, tags, selectable, …) are passed through.

The treeview() helper converts an id/name/children tree into this format, marks the given ids as checked and expands all nodes:

$nodes = treeview(Category::get()->toTree()->toArray(), $selectedIds);

Endpoint

With url_tree, the field sends one request on init:

• Method: GET, URL: url_tree as given plus a data= parameter. Pass the selected ids in the URL query.
• Response (JSON): {"data": [nodes]}.

public function treeview(Request $request)
{
    return response()->json([
        'data' => treeview(Category::get()->toTree()->toArray(), $request->input('selected', [])),
    ]);
}

What is submitted

For every checked node the component adds a hidden input name[] with the node id, and keeps the list in sync on every check/uncheck:

<input type="hidden" name="category_ids[]" value="2">
<input type="hidden" name="category_ids[]" value="4">

When nothing is checked nothing is submitted, so the key is missing: use $request->input('category_ids', []) to clear a relation.

Checking a parent does not check its children (and vice versa); each node is submitted on its own.

The form model, old() and default are not used: after a failed validation the tree shows what the endpoint or data returns. Pass old('category_ids', $current) as the selected ids to keep the user’s choice.

JS behaviour

• Init: initTreeview(root) on .f-treeview-wrap, on page load and for content inserted later, see Dynamic content. Each field is initialized once.
• Checkboxes are always shown, node icons are hidden.
• Data attributes on the wrapper: data-url, data-data (static tree as JSON), data-field-name.

See JavaScript API.

Related

• select2Tree — the same kind of tree as a dropdown.
• nestedset — drag-and-drop ordering of a tree.
